APC SRTG10KXLI Smart-UPS 10kVA Online Rackmount 230V

APC SRTG10KXLI Smart-UPS (RT 10kVA) – Specifications

• Model: SRTG10KXLI

• Type: Rackmount Online Double Conversion UPS

• Capacity: 10000VA / 10000W

• Form Factor: 3U Rackmount (UPS) + 3U Battery

• Input Voltage: 230V

• Output Voltage: 230V

• Input Connection: Hardwire (3-wire, single-phase)

• Output Connections: (6) IEC C13, (2) IEC C19, Hardwire terminals

• Waveform Type: Pure Sine Wave

• Technology: Online Double Conversion

• Battery Type: Internal modular battery pack (extendable)

• Runtime at Full Load: 4–5 minutes (extendable with external battery packs)

• Recharge Time: 3 hours typical

• Display Interface: Multifunction LCD panel

• Communication Interface: SmartSlot, USB, Serial

• Dimensions: 263 x 432 x 773 mm (UPS only)

• Weight: Approx. 118 kg

• Mounting: Rackmount or Tower Convertible

Reliable power with the APC SRTG10KXLI Smart-UPS (RT 10kVA)

The APC SRTG10KXLI Smart-UPS (RT 10kVA) is engineered to deliver high-efficiency, consistent, and secure power for critical enterprise systems. With a full 10000W output, this UPS ensures uninterruptible performance for data centers, network closets, and high-end automation systems.

Double-conversion online design in the APC SRTG10KXLI Smart-UPS (RT 10kVA)

This UPS features online double-conversion technology, offering complete isolation from unstable power sources. Voltage and frequency are fully regulated, protecting sensitive equipment from surges, brownouts, or power distortion—without any transfer time.

Full 10000W output on the APC SRTG10KXLI Smart-UPS (RT 10kVA)

Unlike UPS systems that deliver less usable power, the SRTG10KXLI provides a full 10000 watts, allowing you to operate multiple servers, network switches, or industrial control systems simultaneously, without risking overload.

Pure sine wave output from the APC SRTG10KXLI Smart-UPS (RT 10kVA)

The pure sine wave output ensures clean, stable power delivery that replicates utility-grade electricity. This is essential for equipment with sensitive power requirements, such as blade servers, medical devices, and enterprise storage arrays.

Built for scalability: APC SRTG10KXLI Smart-UPS (RT 10kVA)

Need more runtime? The SRTG10KXLI supports external battery packs, enabling extended backup during long outages. Add multiple battery modules to scale protection based on your environment’s criticality and load profile.

High-performance battery module inside the APC SRTG10KXLI Smart-UPS (RT 10kVA)

The internal modular battery pack provides 4–5 minutes of runtime at full capacity. The system recharges in under 3 hours and offers hot-swappable replacement, minimizing downtime during maintenance.

APC SRTG10KXLI Smart-UPS (RT 10kVA) supports intelligent manageability

Equipped with a SmartSlot, USB, and Serial ports, the UPS can be remotely managed and monitored using SNMP cards and PowerChute software. It integrates easily with remote infrastructure systems for automated shutdowns and live event logging.

User-friendly LCD in the APC SRTG10KXLI Smart-UPS (RT 10kVA)

The multifunction LCD panel provides detailed information on UPS health, battery status, load usage, and event history. Clear navigation keys allow configuration and diagnostics without the need for software.

Versatile connectivity options on the APC SRTG10KXLI Smart-UPS (RT 10kVA)

With (6) IEC C13, (2) IEC C19, and hardwire output terminals, the UPS connects easily to varied equipment profiles—from small rack devices to high-wattage enterprise systems—while maintaining safe load distribution.

Enterprise-grade form factor of the APC SRTG10KXLI Smart-UPS (RT 10kVA)

This 3U rackmount UPS (plus 3U battery) fits standard IT racks and can also be deployed as a standalone tower. Whether in server rooms or edge environments, the form factor supports flexible infrastructure layouts.

Rugged construction and thermal efficiency in the APC SRTG10KXLI Smart-UPS (RT 10kVA)

At 118 kg, the build quality is robust, supporting consistent operation even in high-load and extended runtime scenarios. Built-in fan cooling and thermal sensors protect the system against overheating during prolonged use.

Designed for critical applications: APC SRTG10KXLI Smart-UPS (RT 10kVA)

Ideal for data centers, healthcare IT, financial services, government networks, and industrial automation, the SRTG10KXLI delivers power continuity, management control, and seamless runtime expansion.

Easy maintenance and service access with APC SRTG10KXLI Smart-UPS (RT 10kVA)

The modular architecture supports hot-swappable batteries, quick front-panel access, and replaceable fans—reducing service times and enhancing overall uptime in mission-critical environments.

Why choose the APC SRTG10KXLI Smart-UPS (RT 10kVA) for your infrastructure

The SRTG10KXLI is a powerhouse of secure, consistent, and manageable power. It is built to meet the demands of modern IT and operational infrastructure. With 10000W output, online conversion, and scalable batteries, it keeps you powered and protected at all times.
