Mecer 650VA Line Interactive UPS ME‑650‑VU Backup Power

Mecer 650VA Line Interactive UPS (ME‑650‑VU) — Specifications

• Model: ME‑650‑VU

• Type: Line Interactive UPS

• Capacity: 650 VA / approx. 390 W

• Form Factor: Tower / Desktop

• Input Voltage: 230 V

• Output Voltage: 230 V

• Plug Type: IEC C14 input; IEC C13 outputs (4)

• Waveform Type: Simulated Sine Wave

• Battery Type: Sealed Lead‑Acid, Maintenance‑Free

• Battery Runtime: ~10 min at half load (~200 W)

• Recharge Time: ~4 hours to 90%

• Display: LCD with status icons (battery, load, faults)

• Audible Alarm: Yes (battery mode, overload, fault)

• Interfaces: USB communication port for software shutdown

• Software Included: Power management software

• Dimensions: Approx. 158 × 98 × 280 mm

• Weight: ~4 kg

• Warranty: Standard manufacturer support

Reliable power backup with the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

The Mecer 650VA Line Interactive UPS (ME‑650‑VU) safeguards personal computers, home servers, network equipment, and peripherals against power interruptions. With its 650VA capacity and automatic voltage regulation (AVR), this UPS offers reliable backup and steadies power during brownouts and surges.

Capacity and battery performance of the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Rated at 650 VA / ~390 W, the ME‑650‑VU is suitable for typical desktop setups. At half load (~200 W), it provides about 10 minutes of backup, enough time to save work and shut down safely. Battery recharge takes around 4 hours to reach 90%, ensuring it's ready for multiple outages.

Power cleaning and AVR in the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Featuring line interactive technology, this UPS regulates low and high voltage shifts without using battery power. Built‑in AVR corrects fluctuations, protecting equipment and extending battery life without triggering full battery mode unless necessary.

Simulated sine wave output in the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

The unit produces a simulated sine wave, suitable for most non‑critical devices such as PCs, routers, and home networking gear. While not as clean as pure sine wave, this output meets the demands of everyday office and home environments.

Connectivity and monitoring on the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Through a USB port, the UPS connects to a Windows or macOS computer. The included shutdown software allows automatic shutdown during extended power outages, protecting data and systems. The LCD screen displays real‑time info on battery status, load levels, and fault alerts.

User interface on the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

A simple LCD display shows icons for AC mode, battery mode, overload, and other conditions. Combined with an audible alarm, it ensures users are informed of all power events, helping them respond quickly and protect connected devices.

Physical design of the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Compact and lightweight at around 4 kg, the Mecer ME‑650‑VU fits neatly on or under desks. Measuring approximately 158 × 98 × 280 mm, it occupies minimal space, making it ideal for home offices and small workspaces.

Output options on the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Equipped with four IEC C13 output sockets, the ME‑650‑VU supports PCs, monitors, routers, and external drives. The standard IEC C14 input ensures easy replacement and compatibility with most power cords worldwide.

Battery maintenance and safety in the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

The sealed, maintenance‑free lead‑acid battery is designed for leak‑free operation. Built‑in protection circuits guard against overload, short circuit, and thermal faults, ensuring a safe and reliable backup environment.

Ideal use cases for the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

The ME‑650‑VU is perfect for home offices, small businesses, and network edge installations. It helps prevent data loss during outages, stabilizes sensitive equipment, and supports graceful shutdowns during longer power loss events.

Energy efficiency of the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Thanks to its smart AVR design and low standby losses, this UPS operates efficiently under normal conditions. The line interactive approach ensures minimal battery use while providing solid protection and power conditioning.

Ease of setup with the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Setup is easy: plug in, connect devices, and link via USB for automatic software shutdown. No technical knowledge is required, making it suitable for non‑technical users who still need reliable power backup.

Reliability and warranty of the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

Designed by a trusted brand, the ME‑650‑VU offers dependable operation and long battery life. Standard manufacturer support ensures peace of mind for end users needing everyday protection for sensitive devices.

Summary of the Mecer 650VA Line Interactive UPS (ME‑650‑VU)

The Mecer 650VA Line Interactive UPS (ME‑650‑VU) delivers dependable backup, voltage regulation, and user‑friendly features in a compact, affordable package. Its 650VA capacity, AVR, LCD interface, and USB comms make it ideal for protecting personal workstations, home servers, and key networking devices.
