Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Key Features
- Outdoor IP fingerprint access control reader
- High-precision OP5 optical fingerprint sensor
- 500 dpi fingerprint resolution
- Suprema fingerprint recognition algorithm
- MINEX-certified fingerprint extractor and matcher
- Hardware and software-based Live Finger Detection
- Dual-frequency RFID technology
- Supports 125 kHz EM cards
- Supports 13.56 MHz MIFARE cards
- Supports MIFARE Plus cards
- Supports DESFire and DESFire EV1/EV2/EV3 cards
- Supports FeliCa cards
- NFC and BLE mobile credential support
- Supports up to 500,000 users
- Supports up to 100,000 fingerprint credentials for 1 authentication
- Supports up to 500,000 fingerprint and card credentials for 1:1 authentication
- Stores up to 1,000,000 text logs
- 1.2 GHz quad-core processor
- 2 GB Flash memory and 256 MB RAM
- 10/100 Mbps Ethernet connectivity
- RS-485 connectivity
- OSDP V2 support
- Wiegand input/output
- 2 input channels
- 1 relay output
- IEEE 802.3af PoE support
- Multi-color LED indicator
- Multi-tone buzzer
- IP67 protection
- IK09 impact protection
- Tamper detection
- Compact and rugged outdoor construction
- Suitable for demanding access control environments
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Introduction
The Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID is a rugged outdoor biometric access control device designed for reliable fingerprint and RFID authentication. It combines Suprema's advanced fingerprint recognition technology with dual-frequency RFID support, making it suitable for professional access control installations in demanding environments.
The reader uses a high-precision OP5 optical fingerprint sensor with 500 dpi resolution and Suprema's fingerprint recognition algorithm. It also features Live Finger Detection technology to help distinguish genuine fingerprints from artificial fingerprint materials.
The BEW2-ODPB supports both 125 kHz EM and 13.56 MHz RFID technologies, including MIFARE, MIFARE Plus, DESFire and FeliCa cards. It also supports NFC and BLE mobile credentials, providing flexible authentication options for modern access control systems.
Its IP67 waterproof and dust-resistant construction and IK09 impact protection make it well suited for outdoor doors, gates, warehouses, commercial buildings and other locations where access control equipment may be exposed to demanding conditions.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Price
| Product Price | |
|---|---|
| Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID | KSh 80,000 |
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Key Specifications
| Feature | Details |
| Brand | Suprema |
| Model | BEW2-ODPB |
| Product Type | Outdoor Fingerprint Access Control Reader |
| Biometric | Fingerprint |
| Sensor Type | Optical Sensor (OP5) |
| Fingerprint Resolution | 500 dpi |
| Image Dimension | 272 × 320 pixels |
| Image Bit Depth | 8-bit, 256 grayscale |
| Fingerprint Template | SUPREMA / ISO 19794-2 / ANSI-378 |
| Extractor / Matcher | MINEX Certified and Compliant |
| Live Finger Detection | Supported, Hardware + Software Based |
| RFID Frequency | 125 kHz + 13.56 MHz |
| RFID Cards | EM, MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3, FeliCa |
| Mobile Credentials | NFC, BLE |
| RFID Read Range | Up to 50 mm for EM/MIFARE/DESFire; up to 30 mm for FeliCa |
| Maximum Users | 500,000 |
| Fingerprint Credentials 1 | Up to 100,000 |
| Fingerprint Credentials 1:1 | Up to 500,000 |
| Card Credentials 1:1 | Up to 500,000 |
| Maximum Text Logs | 1,000,000 |
| CPU | 1.2 GHz Quad Core |
| Flash Memory | 2 GB |
| RAM | 256 MB |
| Crypto Chip | Supported |
| LED | Multi-color |
| Sound | Multi-tone Buzzer |
| Ethernet | 10/100 Mbps, Auto MDI/MDI-X |
| Network Protocol | TCP, UDP |
| RS-485 | 1 Channel, Master/Slave Selectable |
| Communication Protocol | OSDP V2 Compliant |
| Wiegand | 1 Channel, Input/Output Selectable |
| Inputs | 2 Channels |
| Relay | 1 |
| PoE | IEEE 802.3af Compliant |
| USB | Not Supported |
| Wi-Fi | Not Supported |
| IP Rating | IP67 |
| IK Rating | IK09 |
| Tamper | Supported |
| Operating Temperature | -20°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 0% to 80%, non-condensing |
| Storage Humidity | 0% to 90%, non-condensing |
| Power | 12V DC, maximum 0.5A |
| Dimensions | 50 × 172 × 43.4 mm bottom / 38.1 mm top |
| Device Weight | 251 g |
| Bracket Weight | 43 g |
These specifications are based on Suprema's current BioEntry W2 documentation for the BEW2-ODPB model.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Performance
The BEW2-ODPB BioEntry W2 delivers fast biometric authentication using a 1.2 GHz quad-core CPU and Suprema's fingerprint recognition algorithm. Its OP5 optical sensor provides 500 dpi fingerprint image capture, while Live Finger Detection adds protection against attempts to authenticate using artificial fingerprints.
The reader can support up to 500,000 users and store up to 1,000,000 text logs, making it suitable for large organizations and access control systems with substantial user databases.
Performance highlights include:
- 1.2 GHz quad-core processor
- 500 dpi optical fingerprint sensor
- MINEX-certified fingerprint matching
- Hardware and software-based Live Finger Detection
- Up to 500,000 users
- Up to 100,000 fingerprint credentials for 1 authentication
- Up to 500,000 fingerprint credentials for 1:1 authentication
- Up to 500,000 card credentials for 1:1 authentication
- Up to 1,000,000 text logs
- Dual-frequency RFID support
- NFC and BLE mobile credential support
- Fast response and authentication performance
- Multi-color visual feedback
- Multi-tone audible feedback
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Connectivity
The BEW2-ODPB provides multiple wired communication interfaces for connection to professional access control systems. It includes 10/100 Mbps Ethernet, RS-485 and Wiegand, allowing flexible installation in different access control environments.
Connectivity features include:
- 10/100 Mbps Ethernet
- TCP and UDP network protocols
- RS-485 interface
- OSDP V2 communication
- Wiegand input/output
- 2 input channels
- 1 relay output
- IEEE 802.3af PoE
- 12V DC power
- Tamper detection
The Ethernet connection allows the BioEntry W2 to communicate over an IP network, while RS-485 and OSDP V2 provide additional connection options for compatible access control equipment. PoE support can also simplify installation by supplying power through the Ethernet connection.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Design And Built
The BEW2-ODPB is designed specifically for demanding outdoor environments. Its IP67 protection helps protect the device from dust and water exposure, while its IK09 impact rating provides enhanced resistance against physical impact.
The reader features a compact vertical form factor measuring approximately 50 × 172 × 43.4 mm at the bottom and 38.1 mm at the top. The device weighs approximately 251 g, while the bracket weighs approximately 43 g.
Design features include:
- Rugged outdoor construction
- IP67 protection
- IK09 impact protection
- High-precision OP5 optical fingerprint sensor
- Compact vertical design
- Multi-color LED indicator
- Multi-tone buzzer
- Tamper detection
- Ethernet connectivity
- RS-485 connectivity
- Wiegand interface
- PoE support
- Suitable for wall-mounted outdoor installation
The BioEntry W2 is designed to operate in temperatures from -20°C to 50°C, making it suitable for a wide range of indoor and outdoor installations.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Ideal Use Cases
The Suprema BEW2-ODPB is ideal for:
- Office access control
- Corporate buildings
- Commercial premises
- Warehouses
- Factories
- Schools and universities
- Hospitals
- Hotels
- Government facilities
- Residential compounds
- Apartment buildings
- Construction sites
- Outdoor gates
- Restricted areas
- Employee access control
- Secure entrances
- Time and attendance systems
- Large-scale biometric access control installations
Its combination of fingerprint authentication, dual-frequency RFID, mobile credential support and rugged outdoor construction makes it suitable for organizations requiring flexible and reliable access authentication.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Pros And Cons
| Pros | Cons |
| Fingerprint and dual-frequency RFID support | No built-in display |
| 500 dpi optical fingerprint sensor | No Wi-Fi |
| MINEX-certified fingerprint matching | Requires compatible access control software |
| Live Finger Detection | |
| Supports up to 500,000 users | |
| Stores up to 1,000,000 text logs | |
| Supports EM, MIFARE, DESFire and FeliCa | |
| Supports NFC and BLE credentials | |
| IP67 protection | |
| IK09 impact protection | |
| Ethernet connectivity | |
| RS-485 and OSDP V2 support | |
| Wiegand support | |
| IEEE 802.3af PoE support | |
| Tamper detection | |
| Rugged outdoor construction |
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID FAQs
What is the Suprema BEW2-ODPB BioEntry W2?
The BEW2-ODPB BioEntry W2 is an outdoor fingerprint access control reader that combines biometric fingerprint authentication with dual-frequency RFID card reading.
Does the BEW2-ODPB support fingerprint authentication?
Yes. It features a high-precision OP5 optical fingerprint sensor with 500 dpi resolution and Suprema's fingerprint recognition technology.
What RFID cards does the BEW2-ODPB support?
The BEW2-ODPB supports 125 kHz EM and 13.56 MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3 and FeliCa cards.
Does the BEW2-ODPB support mobile credentials?
Yes. The current BEW2-ODPB specification lists NFC and BLE mobile credential support.
How many users can the BioEntry W2 support?
The BEW2-ODPB supports up to 500,000 users. It can support up to 100,000 fingerprint credentials for 1 authentication and up to 500,000 fingerprint and card credentials for 1:1 authentication.
How many logs can the BEW2-ODPB store?
The reader can store up to 1,000,000 text logs.
Is the Suprema BioEntry W2 suitable for outdoor use?
Yes. The BEW2-ODPB has an IP67 rating for protection against dust and water and an IK09 impact rating, making it suitable for demanding outdoor environments.
Does the BioEntry W2 support Live Finger Detection?
Yes. The BEW2-ODPB supports hardware and software-based Live Finger Detection.
Does the BEW2-ODPB support PoE?
Yes. The reader supports IEEE 802.3af Power over Ethernet.
Does the BioEntry W2 have Ethernet?
Yes. It has a 10/100 Mbps Ethernet interface with auto MDI/MDI-X support.
Does the BEW2-ODPB support OSDP?
Yes. Its RS-485 interface is OSDP V2 compliant.
Does the BEW2-ODPB support Wiegand?
Yes. It has one Wiegand channel that can be configured as an input or output.
What is the operating temperature of the BioEntry W2?
The BEW2-ODPB is designed to operate from -20°C to 50°C.
What is the price of the Suprema BEW2-ODPB in Kenya?
The listed price for the Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID is KSh 80,000.
Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID Conclusion
The Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID is a rugged and high-performance biometric access control solution designed for organizations that need reliable authentication in demanding environments. With its 500 dpi OP5 optical fingerprint sensor, Live Finger Detection, dual-frequency RFID, NFC and BLE support, 1.2 GHz quad-core processor, 500,000-user capacity, 1,000,000 text-log capacity, Ethernet, RS-485, OSDP V2, Wiegand and PoE support, it provides a flexible solution for modern access control systems.
Its IP67 protection and IK09 impact resistance make it particularly suitable for outdoor doors, gates, warehouses, factories, commercial premises, offices, institutions and other demanding locations.
Priced at KSh 80,000, the Suprema BEW2-ODPB BioEntry W2 Reader Fingerprint Dual RFID is a strong choice for businesses and organizations looking for a durable biometric reader with fingerprint and dual-frequency RFID authentication.
