DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Overview
The DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder is a high-capacity IP surveillance recorder designed for medium to large-scale security installations. It supports up to 32 IP camera channels with resolutions of up to 12MP, making it ideal for businesses, institutions, and commercial facilities. Equipped with Smart H.265+ compression, AI-powered video analytics, 4K HDMI output, and dual SATA HDD bays, it delivers efficient storage management, intelligent monitoring, and reliable 24/7 recording for professional surveillance systems.
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Key Features
- Supports 32 IP camera channels
- Supports IP cameras up to 12MP resolution
- Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG compression
- Up to 160 Mbps incoming bandwidth
- Up to 128 Mbps recording bandwidth
- HDMI (4K) and VGA video outputs
- AI by Recorder with SMD Plus
- AI by Camera supports face detection, face recognition, perimeter protection, people counting, heat map, and stereo analysis
- Supports up to 2 SATA hard drives
- Maximum storage capacity of up to 20TB per HDD
- ONVIF compatibility for third-party IP cameras
- Smart playback and intelligent event search
- Remote monitoring via DMSS mobile application
- Embedded Linux operating system
- Supports ePTZ and one-click arming/disarming
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Price in Kenya
| Product | Price in Kenya |
|---|---|
| DAHUA NVR4232-4KS3 32CH Lite Network Video Recorder | KSh 20,000 – KSh 60,000 |
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Specification Table
| Specification | Details |
|---|---|
| Product | DAHUA NVR4232-4KS3 |
| Channels | 32 IP Channels |
| Maximum Camera Resolution | Up to 12MP |
| Incoming Bandwidth | 160 Mbps |
| Recording Bandwidth | 128 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| Video Compression | Smart H.265+, H.265, Smart H.264+, H.264, MJPEG |
| Video Output | 1 × HDMI (4K), 1 × VGA |
| Storage | 2 SATA HDD Bays |
| Maximum HDD Capacity | Up to 20TB per HDD |
| Playback | Up to 16-channel playback |
| AI Features | SMD Plus, Face Detection, Face Recognition, Perimeter Protection, People Counting, Heat Map, Stereo Analysis |
| Network Port | 1 × Gigabit RJ-45 |
| USB Ports | 2 × USB 2.0 |
| Audio | 1 Audio In, 1 Audio Out |
| Alarm Interface | 4 Alarm Inputs, 2 Alarm Outputs |
| Operating System | Embedded Linux |
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Performance
- Supports simultaneous recording from up to 32 IP cameras
- Records high-resolution video up to 12MP
- Smart H.265+ compression significantly reduces storage and bandwidth requirements
- AI-assisted SMD Plus minimizes false alarms from environmental movement
- Smooth 4K HDMI output for detailed live monitoring
- Fast multi-channel playback for efficient video review
- Stable 24/7 operation for professional surveillance environments
- High-bandwidth architecture supports demanding IP surveillance deployments
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Design and Build
- Compact 1U rack-mountable chassis
- Durable metal construction
- Efficient cooling system for continuous operation
- Professional front-panel interface
- Lightweight design for easy installation
- Designed for commercial surveillance applications
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Connectivity and Compatibility
- Compatible with Dahua IP cameras
- Supports ONVIF-compliant third-party IP cameras
- HDMI and VGA display outputs
- Gigabit Ethernet connectivity
- USB ports for backup and firmware upgrades
- Supports DMSS mobile application
- Compatible with SmartPSS software and web browser management
- Supports remote viewing and management
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Ideal Use Cases
- Corporate office buildings
- Shopping malls
- Hotels and resorts
- Universities and schools
- Hospitals and healthcare facilities
- Warehouses and logistics centers
- Manufacturing plants
- Government institutions
- Large retail stores
- Multi-site commercial surveillance systems
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – FAQs
1. How many cameras does this NVR support?
It supports up to 32 IP cameras.
2. What is the maximum camera resolution supported?
It supports IP cameras with resolutions up to 12MP.
3. Does it support AI features?
Yes. It supports SMD Plus on the recorder and advanced AI features such as face detection, face recognition, perimeter protection, people counting, and heat mapping through compatible AI cameras.
4. How much storage can it accommodate?
It supports two SATA hard drives with capacities of up to 20TB each.
5. Can I monitor my cameras remotely?
Yes. You can remotely access live video and recordings using the DMSS mobile application.
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Pros and Cons
| Pros | Cons |
|---|---|
| Supports up to 32 IP cameras | PoE switch not built in |
| Supports cameras up to 12MP | Hard drives sold separately |
| Dual HDD bays for expanded storage | Requires external PoE switch or injectors |
| Smart H.265+ compression | AI recorder functions are limited compared to higher-end series |
| 4K HDMI output | |
| ONVIF compatibility with third-party cameras |
DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder – Conclusion
The DAHUA NVR4232-4KS3 32CH 1U 2HDDs Lite Network Video Recorder is a dependable and scalable recording solution for professional IP surveillance systems. With support for 32 channels, up to 12MP cameras, dual HDD storage, AI-assisted monitoring, Smart H.265+ compression, and 4K video output, it provides the performance and flexibility required for demanding commercial and institutional security deployments.
