DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Overview
The DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch is a high-performance Layer 2 smart switch designed for professional CCTV surveillance, enterprise networking, and SMB deployments. It features 16 Fast Ethernet PoE ports and 2 Gigabit Combo uplink ports (RJ-45/SFP), providing flexible connectivity for IP cameras, NVRs, and network infrastructure. With DoLynk Care cloud management, 135W PoE budget, Hi-PoE and IEEE 802.3bt support, PoE Watchdog, 250-meter long-distance PoE transmission, and intelligent Layer 2 management features, this switch offers a reliable and scalable networking solution for demanding surveillance applications.
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Key Features
- 16 × 10/100 Mbps RJ-45 PoE ports
- 2 × Gigabit Combo uplink ports (RJ-45/SFP)
- Layer 2 cloud-managed switch
- Supports IEEE 802.3af, IEEE 802.3at, Hi-PoE, and IEEE 802.3bt standards
- Ports 1–2 support up to 90W PoE output
- Total PoE power budget of 135W
- Cloud management through DoLynk Care
- Local web management
- 7.2 Gbps switching capacity
- 5.36 Mpps packet forwarding rate
- PoE Watchdog for automatic device recovery
- Long-distance PoE transmission up to 250 meters
- VLAN support
- Loop protection
- LLDP network topology management
- Intelligent PoE power management
- Full-metal industrial enclosure
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Price in Kenya
| Product | Price in Kenya |
|---|---|
| DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch | KSh 19,000 – KSh 27,000 |
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Specification Table
| Specification | Details |
|---|---|
| Product | DAHUA CS4218-16ET-135 |
| Switch Type | Layer 2 Cloud Managed PoE Switch |
| PoE Ports | 16 × 10/100 Mbps RJ-45 |
| Uplink Ports | 2 × Gigabit Combo (RJ-45/SFP) |
| PoE Standards | IEEE 802.3af, IEEE 802.3at, Hi-PoE, IEEE 802.3bt |
| PoE Output | Ports 1–2: Up to 90W, Ports 3–16: Up to 30W |
| Total PoE Budget | 135W |
| Switching Capacity | 7.2 Gbps |
| Packet Forwarding Rate | 5.36 Mpps |
| MAC Address Table | 8K |
| Packet Buffer | 4 Mbit |
| Jumbo Frame | 15 KB |
| VLAN Support | Up to 32 VLANs |
| Management | Web Management, DoLynk Care Cloud Management |
| PoE Distance | Up to 250 m (Extend Mode) |
| Protection | PoE Watchdog, Loop Protection, Lightning Protection |
| Installation | Desktop or Rack Mount |
| Housing | Full Metal |
| Operating Temperature | -10°C to +55°C |
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Performance
- Delivers reliable Layer 2 switching for enterprise and surveillance networks
- Cloud management enables remote monitoring and configuration
- Supports Hi-PoE and IEEE 802.3bt for powering high-performance devices
- PoE Watchdog automatically detects and restarts unresponsive IP cameras
- Long-distance PoE transmission reaches up to 250 meters in Extend Mode
- 7.2 Gbps switching capacity ensures efficient data forwarding
- Gigabit combo uplinks provide flexible copper or fiber backbone connectivity
- VLAN and loop protection improve network security and stability
- Fanless metal construction ensures dependable 24/7 operation.
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Design and Build
- Durable full-metal enclosure
- Fanless design for silent operation
- Desktop or rack-mount installation
- LED indicators for port and power status
- Industrial-grade construction
- Wide operating temperature for demanding environments
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Connectivity and Compatibility
- Compatible with Dahua IP cameras
- Supports third-party IEEE 802.3af/at/bt PoE devices
- Supports Hi-PoE devices up to 90W
- Compatible with NVRs and DVRs
- Gigabit RJ-45 and SFP combo uplink connectivity
- Supports DoLynk Care cloud platform
- Local web-based management interface
- Compatible with Cat5e, Cat6, and Gigabit fiber networks
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Ideal Use Cases
- Professional CCTV surveillance systems
- Corporate office networks
- Hotels and hospitality facilities
- Shopping malls
- Schools and universities
- Hospitals and healthcare facilities
- Warehouses and logistics centers
- Manufacturing plants
- Government institutions
- Smart building infrastructure
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – FAQs
1. How many PoE ports does this switch provide?
It features 16 Fast Ethernet PoE ports and two Gigabit combo uplink ports.
2. Does it support cloud management?
Yes. It supports centralized cloud management through the DoLynk Care platform along with local web management.
3. What is the total PoE power budget?
The switch provides a total PoE budget of 135W, with Ports 1 and 2 supporting up to 90W each.
4. How far can PoE transmission reach?
In Extend Mode, PoE transmission can reach up to 250 meters at 10 Mbps.
5. Does it support automatic recovery of connected cameras?
Yes. The integrated PoE Watchdog automatically detects and restarts unresponsive PoE devices to maintain continuous operation.
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Pros and Cons
| Pros | Cons |
|---|---|
| Cloud and local web management | Fast Ethernet PoE ports instead of Gigabit |
| 16 PoE ports with Gigabit combo uplinks | 135W PoE budget may limit multiple high-power devices |
| Hi-PoE and IEEE 802.3bt support | Higher cost than unmanaged switches |
| Long-distance PoE up to 250 meters | |
| PoE Watchdog and loop protection | |
| Flexible RJ-45/SFP combo uplinks | |
| Durable fanless metal enclosure |
DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch – Conclusion
The DAHUA CS4218-16ET-135 18-Port Cloud Managed Desktop Switch is an excellent networking solution for professional surveillance and enterprise deployments. With 16 PoE ports, Gigabit combo uplinks, advanced cloud management, intelligent PoE features, long-distance transmission, and robust Layer 2 capabilities, it provides a secure, reliable, and scalable platform for modern IP networking and CCTV infrastructure.
