Cudy 10-Port Gigabit PoE+ Switch (120W)-GS1010PE

• Total Ports: 10 × 10/100/1000Mbps RJ45 Ports

• PoE Ports: 8 × Gigabit PoE+ Ports (IEEE 802.3af/at)

• Uplink Ports: 2 × Dedicated Gigabit Uplink Ports

• PoE Power Budget: 120W Total (Up to 30W per port)

• Switching Capacity: 20 Gbps (Ensures no bottlenecking at full speed)

• Forwarding Rate: 14.88 Mpps

• Operation Modes (DIP Switch):

  • Default: Standard high-speed switching for all ports.

  • VLAN: Isolates PoE ports from each other to improve security and reduce interference.

  • Extend: Reduces speed to 10Mbps on specific ports to push power/data up to 250 meters.

• Special Feature: AI PoE Watchdog (Automatically reboots non-responsive cameras).

• Build: Metal Casing, Fanless (Silent), Rack-mountable (brackets often sold separately).

Cudy 10-Port Gigabit PoE+ Switch (120W)-GS1010PE

The Cudy GS1010PE is a high-efficiency unmanaged switch designed for networks that require robust power delivery and high-speed data transmission. While it shares the "10-port" designation with other models, the "E" version is often noted for its slightly different chassis dimensions and specific focus on silent, fanless operation for office environments. The Cudy 10-Port Gigabit PoE+ Switch (GS1010PE) Price in Kenya is KSh 7,560.

Who Should Buy This Switch? This is a prime choice for small to medium businesses (SMBs) in Nairobi that need to consolidate their power and data needs. If you are setting up a VoIP phone system or a 4K IP camera network, the GS1010PE provides 8 high-speed PoE+ ports while leaving 2 dedicated Gigabit ports free for your router and NVR. At KSh 7,560, it offers a more budget-friendly entry point into the 120W Gigabit class compared to the standard GS1010P.

Cudy GS1010PE Price & Quick Specs

Technical Specifications

Key Professional Features

• Dedicated Gigabit Uplinks: With two dedicated 1000Mbps uplink ports, you don't have to sacrifice any of your 8 PoE ports to connect to your internet source and your storage server (NVR/NAS).

• Intelligent PoE Watchdog: This automated "self-healing" feature continuously monitors connected devices. If an IP camera or Access Point stops responding, the switch automatically power-cycles the port to reboot the device.

• 250m Extend Mode: By toggling the physical DIP switch, you can extend the transmission distance of ports 7-8 up to 250 meters. This is ideal for cameras located at the far edges of a property or warehouse.

• One-Key VLAN Isolation: Quickly isolate ports 1-8 from one another to prevent broadcast storms and increase security, ensuring that an issue with one camera doesn't slow down the entire network.

• Silent & Reliable: The fanless metal design ensures 100% silent operation, making it suitable for placement on a desk or in a quiet office corner without the constant h

Important Usage Notes

[!IMPORTANT]

External Power vs. Internal: The GS1010PE typically utilizes an external power adapter (52V), which helps keep the switch housing cooler and more compact compared to models with internal power supplies.

• Energy Efficiency: Complies with IEEE 802.3az Energy-Efficient Ethernet, automatically reducing power consumption on ports that are not in use or have shorter cables.

• Cable Quality: To maintain the 120W power budget and ensure stable Gigabit speeds over long distances, the use of Pure Copper Cat6 cabling is highly recommended.

Pros and Cons

Conclusion

The Cudy GS1010PE is a reliable and cost-effective workhorse. For KSh 7,560, it delivers enough power and speed to manage a significant portion of a small business's infrastructure without the complexity or noise of enterprise-grade rack switches
