Mecer 1000VA (1 KVA / 800 W) ME‑1000‑WPTU — Specifications
-
Model: ME‑1000‑WPTU
-
Type: Line Interactive UPS (Wall-Mount)
-
Capacity: 1000 VA / 800 W
-
Form Factor: Wall/Panel Mount
-
Input Voltage: 230 V
-
Output Voltage: 230 V
-
Waveform Type: Simulated Sine Wave
-
Plug Type: Hardwire input/output (supported via terminal block accessories)
-
Battery Type: Sealed Lead‑Acid, Maintenance‑Free
-
Battery Runtime: ~7–8 minutes at half load (~400 W)
-
Recharge Time: ~4 hours to 90%
-
Display: LCD with status icons and load bar
-
Audible Alarm: Yes (battery, overload, fault)
-
Interfaces: USB port for shutdown software
-
Software Included: Power management suite
-
Dimensions: Approx. 350 × 240 × 90 mm
-
Weight: ~9 kg
Reliable backup for wall‑mounted devices with the Mecer 1000VA ME‑1000‑WPTU
The Mecer ME‑1000‑WPTU offers dependable power backup in a ultra‑compact, wall-mountable 1 KVA UPS form. Ideal for network devices like DVRs, CCTV cameras, PoE switches, and IPTV boxes, it keeps your devices online during brownouts and power cuts.
Capacity and runtime for the Mecer 1000VA ME‑1000‑WPTU
With 800 W output capacity, this UPS supports routers, NVRs, and small appliances. At half load (~400 W), expect around 7–8 minutes of runtime, enough to safely save footage or reboot network gear. Batteries recharge to 90% in about 4 hours.
Voltage regulation in the Mecer 1000VA ME‑1000‑WPTU
Featuring line interactive AVR, this unit stabilizes voltage by boosting or trimming the line when it drifts. This reduces battery wear and keeps your wall-mounted devices protected without switching to battery until needed.
Form factor designed for wall mounting in the Mecer 1000VA ME‑1000‑WPTU
Unlike tabletop UPS models, this one is built to be mounted on walls or inside network cabinets. At approximately 350 × 240 × 90 mm and weighing 9 kg, it installs neatly behind network racks or inside panels, reducing desktop clutter.
Simulated sine wave output in the Mecer 1000VA ME‑1000‑WPTU
The power output is a simulated sine wave, sufficient for PoE devices, CCTV NVRs, modems, and routers. It supports everyday electronics, albeit less ideal than pure sine wave for very sensitive gear.
Connectivity and monitoring for the Mecer 1000VA ME‑1000‑WPTU
A USB connection allows for safe auto shutdowns via included software. This ensures devices have clean power-down during extended outages. The LCD screen shows real-time status, load levels, and battery alerts for easy monitoring.
User interface simplicity for the Mecer 1000VA ME‑1000‑WPTU
The multifunction LCD shows icons for AC mode, battery charge, load percentage, and alert functions. Combined with a soft buzzer, it alerts you to power events without being disruptive in residential spaces.
Output and connection options on the Mecer 1000VA ME‑1000‑WPTU
Hard-wired input/output terminals support direct connections to devices like routers and switches inside cabinets. For consumer installs, it can be adapted with suitable power outlets.
Battery and safety features in the Mecer 1000VA ME‑1000‑WPTU
The sealed lead‑acid battery is easy to replace and safe for indoor mounting. It includes protections for overloads, short circuits, and overheating, ensuring stable operation in tight spaces.
Ideal use cases for the Mecer 1000VA ME‑1000‑WPTU
Designed for home surveillance systems, network closets, IT racks, or commercial panel installations, this UPS delivers enough backup time and space-saving form to protect essential equipment.
Energy efficiency of the Mecer 1000VA ME‑1000‑WPTU
Low power consumption in standby mode, combined with AVR, makes it energy efficient. Wall-mounted form ensures power is used only when needed, reducing ongoing energy costs.
Installation and maintenance ease for the Mecer 1000VA ME‑1000‑WPTU
Mount the unit using supplied brackets, wire input and output lines, plug in USB, and you’re set. The wall-mount design frees up floor space and keeps equipment protected out of reach.
Reliability and support for the Mecer 1000VA ME‑1000‑WPTU
Built for residential and light commercial use, this UPS is backed by manufacturer support. It’s a practical choice for those seeking unobtrusive, reliable backup in compact installations.
Summary of the Mecer 1000VA (1 KVA) ME‑1000‑WPTU
The Mecer ME‑1000‑WPTU combines a compact wall-mount design with 1 KVA capacity, AVR, LCD monitoring, and USB control. It fits neatly into smart homes, small offices, and network rack spaces where desktop UPS won't do.
