EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Key Features
- 10000VA / 10000W power capacity
- True Online Double-Conversion UPS
- Output power factor of 1.0
- Pure sine wave output
- Zero transfer time (0 ms)
- 4U rack-mount or tower convertible design
- 3.5-inch color LCD display
- USB, RS232, and RS485 communication ports
- Optional SNMP and parallel operation support
- Emergency Power-Off (EPO) function
- Intelligent battery management
- Generator compatible
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Overview
The EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) is a high-capacity enterprise UPS engineered for mission-critical environments including data centers, server rooms, telecommunications networks, industrial automation, and healthcare systems. Using true online double-conversion technology, it continuously converts incoming AC power into DC and back to clean AC power, ensuring connected equipment receives uninterrupted, stable pure sine wave power with zero transfer time during outages.
Designed as a versatile 4U rack-mount system that can also be deployed as a tower, the UPS features intelligent battery management, a 3.5-inch color LCD display, comprehensive communication interfaces, and optional SNMP support for remote management. It also supports external battery expansion, allowing organizations to extend runtime for critical applications.
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Price Table
| Product | Price (KES) |
|---|---|
| EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) | 200,000 – 230,000 (approx.) |
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Key Specs
| Specification | Details |
|---|---|
| Capacity | 10000VA / 10000W |
| UPS Type | Online Double Conversion |
| Phase | Single Phase |
| Output Power Factor | 1.0 |
| Output Waveform | Pure Sine Wave |
| Transfer Time | 0 ms |
| Input Voltage Range | 110–300V AC |
| Output Voltage | 208/220/230/240V AC (Selectable) |
| Communication | USB, RS232, RS485, Optional SNMP |
| Display | 3.5-inch Color LCD |
| Form Factor | 4U Rack Mount / Tower Convertible |
| Battery | 16 × 12V VRLA (Built-in) |
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Performance
- Delivers a full 10000W usable output with a 1.0 power factor
- True online double-conversion technology provides continuous clean power
- Zero transfer time eliminates interruptions during utility failures
- Pure sine wave output protects enterprise servers and networking equipment
- Wide input voltage range minimizes unnecessary battery usage
- Supports external battery cabinets for extended runtime
- Generator compatible for maximum reliability during prolonged outages
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Design & Build
- Professional 4U rack-mount chassis
- Convertible for tower installation
- Heavy-duty metal enclosure
- 3.5-inch color LCD display with real-time monitoring
- High-efficiency cooling system
- Front-access controls for easy management
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Connectivity
- USB communication interface
- RS232 serial communication
- RS485 communication port
- Optional SNMP card for remote monitoring
- Parallel operation support
- Emergency Power-Off (EPO)
- Generator compatibility
- Frequency converter mode (50Hz/60Hz)
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Use Cases
- Data Centers: Enterprise-grade backup for servers and storage systems
- Server Rooms: Continuous protection for rack-mounted infrastructure
- Telecommunications: Ensures uninterrupted communications equipment
- Industrial Automation: Protects control systems and PLCs
- Healthcare Facilities: Maintains stable power for medical equipment
- Financial Institutions: Supports mission-critical banking and transaction systems
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Pros & Cons
| Pros | Cons |
|---|---|
| Full 10000W output with 1.0 power factor | Premium purchase cost |
| True online double-conversion technology | Large 4U rack footprint |
| Pure sine wave output | Heavy due to built-in batteries |
| Zero transfer time | Professional installation recommended |
| Supports external battery expansion and SNMP | Designed primarily for enterprise deployments |
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) FAQs
Q1: Is this a true online UPS?
Yes. It uses online double-conversion technology to provide uninterrupted pure sine wave power with zero transfer time.
Q2: Can the UPS support longer backup times?
Yes. It supports external battery extension units, allowing runtime to be expanded according to application requirements.
Q3: Does it support remote monitoring?
Yes. It includes USB, RS232, and RS485 communication, with optional SNMP support for advanced remote management.
Q4: What environments is this UPS designed for?
It is ideal for data centers, enterprise server rooms, telecom infrastructure, healthcare facilities, industrial control systems, and other mission-critical applications requiring uninterrupted power.
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) Verdict
The EVI 10000VA / 10000W Rack Mount Online Single Phase UPS (EP-UPS10000P11OR) is a premium enterprise-class UPS that delivers maximum power protection for demanding environments. Featuring true online double-conversion technology, a 1.0 output power factor, pure sine wave output, zero transfer time, intelligent battery management, external battery expansion, and comprehensive communication options, it is an excellent choice for organizations seeking reliable, uninterrupted power for mission-critical IT infrastructure.
