Dahua LCH86-MC410-B 86" UHD Smart Interactive Whiteboard

Specifications for Dahua LCH86-MC410-B 86" UHD Smart Interactive Whiteboard

• Screen Size: 86 inches

• Resolution: 3840 x 2160 (4K UHD)

• Display Type: LED touchscreen, anti-glare tempered glass

• Touch Technology: Infrared, 20-point multi-touch

• Operating Systems: Android (built-in) and Windows (via OPS slot)

• Wireless Sharing: Supports multi-device screen casting

• Memory (Android): 4GB RAM / 32GB storage (typical)

• Speakers: Built-in stereo speakers

• Microphones: Integrated for voice input and conferencing

• Camera: Built-in (typically 5MP)

• Ports: HDMI, USB 3.0, USB-C, VGA, LAN, Audio In/Out

• Connectivity: Wired LAN, optional Wi-Fi

• Viewing Angle: 178°

• Touch Response Time: <10ms

• Mounting: Wall-mount and trolley compatible (VESA support)

• Power Supply: AC 100–240V, 50/60Hz

• Design: Silver-black bezel, slim frame, protective glass

• Use Case: Ideal for classrooms, boardrooms, and collaborative presentations

Description for the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

Immersive Visual Experience with the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

The Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard delivers a stunning 4K UHD resolution (3840 × 2160) on its expansive 86-inch DLED display. With a 16:9 aspect ratio, 350 cd/m² brightness, and a wide 178° viewing angle, it ensures clear and vibrant visuals from any position in the room. The anti-glare tempered glass with a 7H hardness rating provides durability and a comfortable viewing experience, making it ideal for large conference rooms, classrooms, and collaborative spaces.

Seamless Interaction and Touch Responsiveness on the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

Experience natural and intuitive interaction with the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard. Its infrared touch technology supports up to 20 simultaneous touch points, allowing multiple users to write or draw using fingers or stylus pens. The high touch resolution (32767 × 32767) and rapid response time (<10 ms) ensure smooth and precise input, enhancing collaborative sessions and presentations.

Powerful Performance and Dual OS Support in the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

Equipped with a quad-core A55 CPU, 4 GB RAM, and 32 GB internal storage, the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard runs on Android 9.0, providing a robust platform for various applications. For users requiring Windows OS, an optional OPS (Open Pluggable Specification) module can be installed, offering flexibility to switch between Android and Windows environments seamlessly.

Advanced Connectivity and Wireless Sharing with the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

The Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard offers versatile connectivity options, including HDMI, USB 3.0, RJ-45, RS-232, and audio ports. Its dual-band Wi-Fi (2.4 GHz/5 GHz) and hotspot capabilities enable wireless screen sharing from multiple devices such as smartphones, tablets, and laptops. Features like screen grouping, host mode, and split-screen display (up to 9 screens) facilitate dynamic and interactive sessions.

Integrated Camera and Audio Features in the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

Enhance your video conferencing experience with the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard. It comes with a built-in 5 MP camera supporting resolutions up to 1080p@30fps, ensuring clear and detailed video output. The integrated dual microphones with noise reduction, echo cancellation, and AGC (Automatic Gain Control) provide clear audio capture within a 6–8 meter range, making remote communication more effective.

Explore a Related Product to the Dahua LCH86-MC410-B 86-Inch UHD Smart Interactive Whiteboard

For those seeking a slightly smaller interactive display with similar features, consider the Dahua LCH75-MC410-B 75-Inch UHD Smart Interactive Whiteboard. It offers the same 4K resolution, touch capabilities, and dual OS support, making it suitable for medium-sized meeting rooms and classrooms.
