Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Overview
The Dahua XVR5108HS-5M-I3/T 8 Channel Penta-brid 5MP Digital Video Recorder is a high-performance surveillance solution designed for small to medium security installations that require enhanced image clarity and advanced AI features. It supports Penta-brid input (HDCVI, AHD, TVI, CVBS, and IP cameras), allowing flexible integration of both analog and IP systems. With support for 5MP recording, WizSense AI technology, H.265 compression, and up to 1 HDD storage, it delivers efficient, intelligent, and high-quality video management for modern security environments.
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Key Features
- 8-channel Penta-brid video input (HDCVI/AHD/TVI/CVBS/IP)
- Supports up to 5MP@12fps / 1080p@25fps encoding
- WizSense AI with human and vehicle detection
- Smart Motion Detection (SMD Plus)
- H.265 / Smart H.265+ compression technology
- Supports up to 12 IP camera channels (depending on mode)
- AI functions including AcuPick, face detection, and perimeter protection
- HDMI and VGA simultaneous video output
- Remote access via DMSS mobile application
- Smart playback and intelligent video search
- 1 SATA HDD support (up to 16TB)
- Dual-stream recording for bandwidth efficiency
- ONVIF compatibility for third-party IP cameras
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Price in Kenya
| Product | Price in Kenya |
|---|---|
| Dahua XVR5108HS-5M-I3/T 8 Channel 5MP WizSense DVR | KSh 13,000 – KSh 25,000 |
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Specification Table
| Specification | Details |
|---|---|
| Product | Dahua XVR5108HS-5M-I3/T Digital Video Recorder |
| Channels | 8 Channels (Penta-brid) |
| Video Input | HDCVI / AHD / TVI / CVBS / IP |
| IP Camera Support | Up to 12 channels |
| Max Recording | 5MP@12fps / 1080p@25fps |
| Compression | H.265 / Smart H.265+ / H.264 |
| AI Features | WizSense (SMD Plus, AcuPick, Perimeter Protection, Face Detection) |
| Storage | 1 SATA HDD (up to 16TB) |
| Video Output | HDMI / VGA |
| Network | RJ45 Ethernet |
| Remote Access | DMSS App, Web Client, CMS software |
| USB Ports | 2 × USB 2.0 |
| Power Supply | 12V DC |
| Operating Temperature | –10°C to +55°C |
| Form Factor | 1U compact DVR |
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Performance
- Delivers high-definition 5MP recording for clearer surveillance detail
- AI-powered WizSense improves detection accuracy and reduces false alarms
- Supports mixed camera systems for flexible upgrades
- Efficient H.265 compression reduces storage and bandwidth usage
- Smooth live view and playback across multiple channels
- Advanced search tools for quick incident retrieval
- Stable 24/7 recording performance for continuous monitoring
- Optimized for residential and small commercial security systems
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Design and Build
- Compact 1U metal chassis for easy installation
- Durable construction for long-term operation
- Efficient cooling design for continuous use
- Simple interface for quick configuration
- Lightweight and rack-friendly structure
- Built for stable indoor surveillance deployment
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Connectivity and Compatibility
- Supports HDCVI, AHD, TVI, CVBS, and IP cameras
- Compatible with Dahua and ONVIF-supported IP cameras
- Remote monitoring via DMSS mobile app
- Web and CMS software access support
- HDMI and VGA display outputs
- RJ45 network connectivity
- USB backup and firmware upgrade support
- Works in hybrid CCTV environments
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Ideal Use Cases
- Home security systems
- Small retail shops
- Offices and business premises
- Apartments and gated communities
- Schools and clinics
- Small warehouses
- Parking and entrance monitoring
- Hybrid CCTV upgrades
- Budget-friendly 5MP surveillance systems
- Remote monitoring setups
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – FAQs
1. How many cameras does it support?
It supports 8 analog channels plus up to 12 IP cameras depending on configuration.
2. Does it support 5MP cameras?
Yes, it supports up to 5MP resolution at reduced frame rates (typically 12fps).
3. Does it include AI features?
Yes, it includes WizSense AI with SMD Plus, AcuPick, and perimeter protection.
4. Can I view cameras remotely?
Yes, via the DMSS mobile application.
5. How much storage does it support?
It supports 1 SATA HDD up to 16TB capacity.
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Pros and Cons
| Pros | Cons |
|---|---|
| Supports 5MP recording | Limited to 1 HDD slot |
| Advanced WizSense AI features | Lower FPS at higher resolution |
| Supports up to 12 IP cameras | Not ideal for large enterprise systems |
| Efficient H.265 compression | Requires configuration for best AI use |
| Flexible Penta-brid compatibility | |
| Remote access via DMSS |
Dahua 8 Channel Penta-brid 5MP Digital Video Recorder – XVR5108HS-5M-I3/T – Conclusion
The Dahua XVR5108HS-5M-I3/T 8 Channel Penta-brid 5MP DVR is a powerful and flexible surveillance recorder designed for users who need higher resolution recording and intelligent AI features. With 5MP support, WizSense analytics, hybrid camera compatibility, and efficient compression, it is an excellent choice for modern home and small business security systems.
