Cudy 24-Port Gigabit PoE+ Switch with 2 SFP Slots -GS1028PS2

• Total Ports: 26 Ports (24 PoE+ Ports + 2 Uplink SFP Slots)

• PoE Ports: 24 × 10/100/1000Mbps Gigabit RJ45 (IEEE 802.3af/at)

• Uplink Ports: 2 × 1.25Gbps SFP Fiber Slots (for long-distance backbone)

• Total PoE Budget: 300W (Up to 30W per individual port)

• Switching Capacity: 56 Gbps (High-bandwidth backbone)

• Forwarding Rate: 41.664 Mpps

• Operation Modes (DIP Switch):

  • Default: Normal communication between all ports.

  • VLAN: Isolates ports 1–24 from each other to prevent broadcast storms.

  • Extend: Power/Data up to 250 meters (at 10Mbps) on ports 17–24.

• Reliability: AI PoE Watchdog automatically reboots non-responsive cameras.

• Cooling: Smart Fan System (Adjusts speed based on power load).

• Build: 19-inch Metal Case (1U Rack-mount kit included).

Cudy 24-Port Gigabit PoE+ Switch with 2 SFP Slots -GS1028PS2

The Cudy GS1028PS2 is a professional-grade, rack-mountable network switch designed for large-scale deployments such as enterprise offices, schools, and comprehensive IP surveillance systems. It features 24 full Gigabit PoE+ ports and a significant 300W total power budget, ensuring that even power-hungry devices like Wi-Fi 6 access points and PTZ cameras run reliably. The Cudy 24-Port Gigabit PoE+ Switch (GS1028PS2) Price in Kenya is KSh 24,300.

Who Should Buy This Switch? This switch is built for IT administrators and security integrators in Nairobi managing high-density environments. With 24 Gigabit ports, it can replace multiple smaller switches, simplifying cable management in a server rack. The inclusion of SFP slots makes it perfect for connecting to a fiber backbone, providing a lightning-fast, interference-free link to the core network. At KSh 24,300, it offers exceptional value for a high-capacity 300W Gigabit solution.

Cudy GS1028PS2 Price & Quick Specs

Technical Specifications

Key Professional Features

• Massive 300W PoE Budget: With 300W available, you can power up to 24 standard IP cameras (averaging 12W) or a dozen high-performance Wi-Fi 6 Access Points simultaneously without power throttling.

• Dual SFP Fiber Uplinks: The two 1.25Gbps SFP slots allow for high-speed fiber-optic connections. This is critical for connecting switches across different floors or buildings, ensuring the uplink doesn't become a bottleneck for the 24 Gigabit ports.

• CCTV / Extend Mode: Specifically designed for large compounds. When enabled, ports 17-24 can transmit power and data up to 250 meters, allowing you to install cameras far beyond the standard 100-meter Ethernet limit.

• One-Key VLAN Isolation: Protect your network from broadcast storms and unauthorized access. Toggling the VLAN mode isolates the 24 PoE ports from each other, ensuring they can only communicate with the SFP or Uplink ports.

• PoE Watchdog (Auto-Healing): The switch intelligently monitors the status of connected PoE devices. If a camera or VoIP phone stops responding, the switch automatically reboots the port to restore service.

Important Usage Notes

[!IMPORTANT]

Fiber Ready: To use the SFP ports, you will need to purchase compatible SFP Transceiver Modules and fiber patch cords, as these are not included in the box.

• Rack Installation: This switch is standard 19-inch rack size ($1U$). Ensure your server cabinet has adequate depth ($>210mm$) and ventilation for the side-exhaust fans.

• Smart Cooling: The fans are "Smart," meaning they only spin at high speeds when the PoE load is high. In low-power scenarios, the switch remains relatively quiet for office use.

Pros and Cons

Conclusion

The Cudy GS1028PS2 is a high-capacity "core" or "edge" switch for demanding environments. For KSh 24,300, it provides the port density, power budget, and fiber connectivity needed to run a professional network or security system with 100% reliability.
