BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI
Key Specifications
- Model: BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI
- Product Type: Professional Analog to 12G-SDI Video Converter
- Analog Video Inputs: Component, Composite (NTSC/PAL), S-Video
- SDI Outputs: 2 × 12G-SDI Outputs
- Maximum Video Resolution: Up to DCI 4K (4096 × 2160) at 60fps
- Audio Inputs: 2-Channel Balanced Analog XLR & 4-Channel AES/EBU Digital Audio
- Timecode Support: XLR Timecode Input
- Ethernet: Gigabit Ethernet with PoE Support
- Configuration: USB & Ethernet Software Control
- Power Supply: Universal AC Power Supply Included
- Construction: Rack-Mountable Metal Housing
- Application: Broadcast, Live Production, Studio & Professional AV
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI OVERVIEW
The BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI is a professional broadcast converter designed to transform analog video sources into high-quality 12G-SDI signals for modern broadcast and production workflows. It supports component, composite, and S-Video inputs, making it ideal for integrating legacy analog equipment such as Betacam SP decks, VHS players, HDV cameras, gaming consoles, and other analog devices into SDI-based production systems.
Supporting resolutions up to DCI 4K (4096 × 2160) at 60fps, the converter features dual independent 12G-SDI outputs, professional balanced XLR audio inputs, AES/EBU digital audio embedding, Ethernet control with Power over Ethernet (PoE), and intelligent cooling for reliable continuous operation. These features make it suitable for television studios, OB vans, live events, post-production facilities, and broadcast installations.
At KSh 36,300, the Blackmagic Mini Converter Analog to SDI 12G provides an advanced solution for upgrading analog video workflows to modern SDI infrastructure.
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI PRICE IN KENYA
| Product | Price (KSh) |
|---|---|
| BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI | 36,300 |
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI FULL SPECIFICATIONS
| Specification | Details |
|---|---|
| Product Name | BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI |
| Product Type | Analog to 12G-SDI Broadcast Converter |
| Analog Video Inputs | Component, Composite (NTSC/PAL), S-Video |
| SDI Outputs | 2 × 12G-SDI Outputs |
| Maximum Resolution | DCI 4K (4096 × 2160) at 60fps |
| SDI Standards | SD, HD, 3G, 6G & 12G-SDI |
| Analog Audio Inputs | 2 × Balanced XLR |
| Digital Audio Inputs | 4 × AES/EBU |
| Timecode Input | Yes (via XLR) |
| Ethernet | Gigabit Ethernet with PoE |
| USB | USB for Configuration & Updates |
| Reclocking | Yes |
| Cooling | Intelligent Active Cooling |
| Power Supply | Universal AC Adapter Included |
| Housing | Metal Rack-Mountable Design |
| Operating Temperature | 0°C to 40°C |
| Included Accessories | Converter, Universal Power Supply with International Plug Adapters |
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI BUILD QUALITY AND DESIGN
The converter features a durable all-metal chassis designed for professional installations. Its compact rack-friendly form factor incorporates intelligent thermal management to maintain reliable performance during extended broadcast and production sessions.
Gigabit Ethernet with PoE support enables centralized management and power over a single cable in compatible installations, reducing cabling complexity.
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI PERFORMANCE
Video Performance
Converts analog video into broadcast-quality SDI with support for SD, HD, Ultra HD, and DCI 4K formats up to 2160p60.
Audio Performance
Supports professional balanced analog XLR audio and AES/EBU digital audio embedding directly into the SDI signal for synchronized audio and video.
Broadcast Performance
Dual independent 12G-SDI outputs provide flexible routing to multiple production devices while maintaining excellent signal integrity.
Reliability
Built for continuous professional operation with intelligent cooling, SDI reclocking, and Ethernet management capabilities.
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI COMPATIBILITY AND CONNECTIVITY
Compatibility
- Betacam SP equipment
- VHS players
- HDV cameras
- Analog broadcast cameras
- Production switchers
- Broadcast routers
- Professional SDI monitors
- Video recorders
- Live production systems
Connectivity
- Component Video Input
- Composite Video Input
- S-Video Input
- 2 × 12G-SDI Outputs
- Balanced XLR Audio Inputs
- AES/EBU Digital Audio Inputs
- USB
- Gigabit Ethernet with PoE
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI IDEAL USE
- Television broadcasting
- Live event production
- Studio installations
- Legacy equipment integration
- Video archiving
- Post-production
- Corporate AV
- Church broadcasting
- Educational media production
- Professional video conversion
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI PROS & CONS
| Pros | Cons |
|---|---|
| Supports DCI 4K up to 60fps | Higher cost than basic converters |
| Dual independent 12G-SDI outputs | Requires AC power |
| Professional XLR and AES/EBU audio embedding | Designed primarily for professional users |
| Ethernet with PoE support | Rack installation may require additional accessories |
| Rugged metal construction with active cooling | Larger than Micro Converter models |
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI FAQs
Does this converter support 4K video?
Yes. It supports analog video conversion to DCI 4K (4096 × 2160) at up to 60fps.
Can it connect legacy analog equipment to SDI systems?
Yes. It is designed for connecting devices such as Betacam SP, VHS players, HDV cameras, and other analog equipment to modern SDI workflows.
How many SDI outputs are available?
It provides two independent 12G-SDI outputs for simultaneous connection to multiple professional devices.
Does it support professional audio embedding?
Yes. It supports balanced analog XLR audio, AES/EBU digital audio, and timecode input for professional broadcast workflows.
Can the converter be managed remotely?
Yes. It supports USB and Gigabit Ethernet configuration, including Power over Ethernet (PoE) functionality.
BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI CONCLUSION
The BLACKMAGIC MINI CONVERTER ANALOG TO SDI 12G – BMMINCONANSDI is a professional-grade broadcast converter that bridges legacy analog video equipment with modern SDI production systems. Featuring support for DCI 4K 60fps, dual 12G-SDI outputs, professional audio embedding, Ethernet management with PoE, and rugged construction, it is an excellent choice for broadcasters, production studios, and AV professionals. At KSh 36,300, it delivers powerful performance for demanding broadcast and live production environments.
