Blackmagic Mini Converter Analog to SDI 12G
The Blackmagic Mini Converter Analog to SDI 12G is a professional broadcast video converter designed to convert analog component, S-Video, NTSC, and PAL video signals into 12G-SDI for integration with modern broadcast and production systems. It is ideal for broadcasters, production studios, post-production facilities, houses of worship, AV integrators, and organizations upgrading legacy analog equipment to Ultra HD workflows.
Supporting SD, HD, Ultra HD, and 4K DCI resolutions up to 2160p60, the converter features dual 12G-SDI outputs, balanced analog audio inputs, AES/EBU digital audio support, timecode input, USB and Ethernet configuration, and a universal power supply, making it an excellent solution for converting legacy video sources into professional SDI production environments.
Blackmagic Mini Converter Analog to SDI 12G Price
| Product | Price |
|---|---|
| Blackmagic Mini Converter Analog to SDI 12G | KSh 36,300 |
Blackmagic Mini Converter Analog to SDI 12G Features
- Converts analog video to 12G-SDI
- Supports SD, HD, 6G-SDI, and 12G-SDI formats
- Supports Ultra HD and 4K DCI up to 2160p60
- 2 × independent 12G-SDI outputs
- Component, S-Video, NTSC, and PAL analog video inputs
- 2-channel balanced analog audio input
- 4-channel AES/EBU digital audio input
- Timecode input support
- Automatic video format detection
- USB and Ethernet configuration
- Remote management support
- Compact metal enclosure
- Universal power supply included
- Designed for continuous professional operation
Blackmagic Mini Converter Analog to SDI 12G Specifications
| Specification | Details |
|---|---|
| Brand | Blackmagic Design |
| Model | Mini Converter Analog to SDI 12G |
| Product Type | Analog to SDI Video Converter |
| Analog Video Inputs | Component, S-Video, NTSC, PAL |
| SDI Outputs | 2 × 12G-SDI |
| Analog Audio Input | 2-Channel Balanced XLR |
| Digital Audio Input | 4-Channel AES/EBU |
| Timecode Input | Supported |
| Maximum Resolution | 3840 × 2160p60 Ultra HD |
| Maximum DCI Resolution | 4096 × 2160p60 |
| Supported Formats | SD, HD, 6G-SDI, 12G-SDI |
| USB | Configuration and Firmware Updates |
| Ethernet | Remote Configuration and PoE Support |
| Construction | Metal Housing |
| Power Supply | Universal AC Adapter Included |
Blackmagic Mini Converter Analog to SDI 12G Performance and Usage Overview
The Blackmagic Mini Converter Analog to SDI 12G enables legacy analog equipment to integrate seamlessly into today's professional SDI production environments. It converts analog component, composite, and S-Video signals into high-quality SDI outputs while supporting modern broadcast standards up to Ultra HD 4K60.
With dual independent 12G-SDI outputs, embedded professional audio, Ethernet management, and timecode support, it is ideal for digitizing archival media, connecting legacy cameras and playback devices, and incorporating analog equipment into live production, broadcast, and post-production workflows.
Blackmagic Mini Converter Analog to SDI 12G Connectivity
- Component video input
- Composite NTSC/PAL input
- S-Video input
- 2 × 12G-SDI outputs
- 2-channel balanced XLR audio input
- 4-channel AES/EBU audio input
- Timecode input
- USB configuration port
- Ethernet port with PoE support
Blackmagic Mini Converter Analog to SDI 12G Compatibility
- Betacam SP decks
- VHS players
- HDV cameras
- Analog camcorders
- Professional SDI switchers
- Blackmagic ATEM switchers
- SDI routers
- Broadcast recorders
- Professional production systems
- Ultra HD broadcast workflows
Blackmagic Mini Converter Analog to SDI 12G Build Quality and Design
- Rugged all-metal enclosure
- Compact desktop and rack-compatible design
- Professional locking connectors
- Efficient thermal management
- Front-panel status indicators
- Designed for 24/7 broadcast environments
- Universal power supply included
Blackmagic Mini Converter Analog to SDI 12G Ideal Applications and Use Cases
- Television broadcasting
- Live event production
- Studio installations
- Legacy equipment integration
- VHS and Betacam digitization
- Church AV systems
- Educational media production
- Broadcast archives
- Post-production facilities
- Professional AV installations
Blackmagic Mini Converter Analog to SDI 12G Pros and Cons
| Pros | Cons |
|---|---|
| Converts legacy analog video to 12G-SDI | Premium price compared to HD-only converters |
| Supports Ultra HD 4K60 workflows | Intended primarily for professional users |
| Dual independent 12G-SDI outputs | Requires analog source equipment |
| Professional audio embedding and timecode support | External power supply required |
| Ethernet remote management and PoE support | Larger than Micro Converter models |
Blackmagic Mini Converter Analog to SDI 12G FAQs
1. What does the Blackmagic Mini Converter Analog to SDI 12G do?
It converts analog component, S-Video, NTSC, and PAL video signals into professional SDI, supporting resolutions up to Ultra HD 4K60.
2. What is the maximum supported resolution?
It supports Ultra HD 3840 × 2160 at 60 fps and 4K DCI 4096 × 2160 at 60 fps.
3. How many SDI outputs does it have?
It includes two independent 12G-SDI outputs for connecting multiple professional devices simultaneously.
4. Can it embed audio into the SDI signal?
Yes. It supports balanced analog XLR audio and AES/EBU digital audio, embedding audio directly into the SDI output.
5. Does it support Ethernet management?
Yes. It features Ethernet connectivity with remote configuration and PoE support for professional installations.
6. What analog devices can be connected?
It supports Betacam SP decks, VHS players, HDV cameras, game consoles, set-top boxes, and other analog video equipment.
7. Is it suitable for professional broadcast production?
Yes. Its 12G-SDI connectivity, Ultra HD support, dual SDI outputs, professional audio embedding, Ethernet management, and rugged construction make it ideal for broadcast, live production, and professional AV installations.
Blackmagic Mini Converter Analog to SDI 12G Conclusion
The Blackmagic Mini Converter Analog to SDI 12G is a powerful solution for integrating legacy analog equipment into modern SDI production environments. Featuring Ultra HD 4K60 support, dual 12G-SDI outputs, professional audio embedding, Ethernet management, and robust broadcast-grade construction, it delivers outstanding performance for television studios, live productions, post-production facilities, and AV installations.
At KSh 36,300, it is an excellent investment for broadcasters, production companies, educational institutions, and AV professionals seeking reliable, high-quality analog-to-SDI conversion.
